NVR Installation – Connecting the Cameras to the NVR
Ensure the NVR is powered on, and is located within 3m of the cameras you wish to add. Connect the AC power connection to the camera’s power input, and ensure the camera is being plugged into an active power outlet. On the NVR itself, right click on the mouse to reveal the Quick Menu From the Quick Menu, select IPC Channel Config, as seen... -
NVR Installation – Connecting the NVR to an HDMI Monitor
Input the HDMI cable into the HDMI output on your NVR, and plug the other end of the HDMI cable into the HDMI input on your television or monitor. Please be aware that you must plug the other end of the HDMI cable into an input, like on a television or monitor, and not an HDMI output like on a laptop. Once you have... -
NVR Operation – New Password
After you’ve gone through the Setup Wizard, you will be asked to enter a password that will be used to protect your Zosi NVR from unwanted access. A password it not mandatory. If you wish to skip setting a password for your NVR, select “OK”. To set a new password: Using the mouse, select the text field beneath “New Password”. The virtual keyboard will appear.... -
NVR Installation – Connecting the NVR to the Internet
To connect the NVR to the internet, take one end of the Ethernet cable and plug it into the NVR’s Ethernet port. Take the other end of the Ethernet cable and plug it into an active modem or router. The lights next to the NVR’s Ethernet port will begin to blink green and yellow if it’s successfully transmitting data. -
NVR Operation – Setup Wizard
The Setup Wizard is used to configure your Zosi NVR the first time you power it on. The Setup Wizard provides several options that ensure your NVR is displaying accurate time and date information on your recordings. These settings can also be found in the Basic > System menu. Please note: The above video was created for use with the Zosi NVR system, but also displays... -
NVR Operation – Live View
Live View is the default screen you will see while viewing your channels. It displays the live video feed. Please note: The above video was created for use with the Zosi NVR system, but also displays the same information used with certain models of Zosi NVRs. Use the mouse and right click anywhere and bring up the Quick Menu. If you’ve selected a layout that enables... -
NVR Operation – Quick Menu
The Quick Menu can be easily accessed from the Live View screen by right clicking on the mouse. It contains several options to customize and configure your Zosi NVR. The Quick Menu options, from top to bottom are: Single View – View the selected channel in full screen. Multi View – Change the Live View layout and view multiple channels at once Start Scan – Select to automatically cycle... -
NVR Operation – Playback
The Playback menu allows you to view the video segment that is currently being recorded. It is useful for viewing the previous half hour of footage immediately. To access the Playback menu, right click on the Live View screen to bring up the Quick Menu. Select the Playback option. If you are unable to view the entire Playback bar, you may have Overscan enabled. Disable the Overscan... -
NVR Operation – IPC Channel Config
The IPC Channel Config menu is used to Add and Remove individual IP cameras from your NVR. Reset IPC – Resets the credentials of the selected camera Search – Search your local area network (LAN) for an IP camera. This will also find cameras that are physically attached to the NVR via Ethernet cable. Wifi Add – Use this to add your IP cameras to the device... -
NVR Operation – Setup Menu
The Setup Menu contains several different options that will let you configure and customize your Zosi NVR. The Setup Menu is where you will control most of the settings and recordings on your Zosi NVR system. Basic – Customize personal settings, as well as date and time information. Live – Contains settings to change display layouts and colour settings. Record – Set up recording options for your channels.... -
NVR Operation – Setup > Basic
Basic > System The Setup > Basic menu allows you to control the basic functions of your NVR through the three tabs. The Basic > System tab enables you to change the date and time settings for your Zosi NVR, along with other customization options. The Basic > System menu contains several settings to personalize your Zosi NVR. The options, from top to bottom... -
NVR Operation – Setup > Live
The Setup > Live menu allows you to customize settings related to the NVR’s Live View page. Live > Live Personalize the names of your cameras and change colour settings. Please note: The above video was created for use with the Zosi DVR system, but also displays the same Live > Live menu used with certain models of Zosi NVRs. 1. Channel List: List of...
